700-HR Multi-Function, Multi-Range Timing Relay
Representative Rendering, Not The Actual Product
700-HR General Purpose Dial Timing Relay, Multi-Function, 2 Timed Contacts w/ No Voltage Inputs, Multi-Mode (6 Functions), 0.05 seconds to 300 hours, DPDT Timed, 100...240V AC 50/60Hz / 100...125V DC
Product Details
| CONTROL RELAY DATA | |
|---|---|
| Type of Timer | Multi-Function, 2 Timed Contacts w/ No Voltage Inputs |
| Timing Mode | Multi-Mode (6 Functions) |
| Contact Configuration | DPDT Timed Contact Arrangement |
| Timing Range | 0.05 seconds to 300 hours |
| Coil Voltage | 100...240V AC 50/60Hz / 100...125V DC |
